5.Adopted with high-temperature color temperature dynamic adjustment algorithm, it automatically corrects color parameters in high-temperature scenarios, suppresses yellowing and color deviation, and maintains consistent screen color performance.
6.It adopts fully bonded OCA optical glue and low-temperature resistant special materials, preventing glue hardening and embrittlement in low-temperature environments, so as to avoid touch layer separation and sensing failure.
7.The screen frame adopts dispensing bonding and fully enclosed waterproof sealing rings, blocking moisture and condensed water from penetrating into the inner cavity to keep the screen clear at all times.
Specificaitons
| Items |
Specifications |
| Viewing Angle |
89 Typ. |
| Display Surface Treatment |
Anti-glare |
| Contrast Ratio |
1000 Typ. |
| Support Color |
16.7M Colors ( RGB 8-bits ) |
| Transmittance |
＞85% |
| Touch Report Rate |
≥100HZ |
| Touch Response Time |
≤25ms |
| Support Touch Points |
10 points Typ. |
| Impact resistance |
≥IK07 |
Yes. It has 1000 nits high brightness and AG anti-glare matte cover glass, effectively eliminating reflection and ensuring clear viewing even in strong sunlight.
2.Will the touch work abnormally in high or low temperatures?No. It uses an industrial-grade wide-temperature chip (-20℃ to +70℃) and low-temperature compensation algorithm, ensuring stable touch without lag, failure or drift.
3.Does the screen yellow or change color after long use in high temperatures?No. With high-temperature color temperature dynamic adjustment algorithm and anti-yellowing materials, it maintains consistent color and no yellowing.
4.Is the screen durable and impact-resistant?Yes. It uses 3 mm thick cover glass with IK10 protection level, making it sturdy, damage-resistant and easy to clean.
5.Is this module reliable in humid or low-temperature environments?Yes. It uses fully bonded OCA and low-temperature resistant adhesive to avoid layer separation. The fully sealed waterproof structure blocks moisture and condensed water effectively.
