Specifications:
| Touch Points |
1-10 Points |
| Impact resistance |
≥IK07 |
| Ink adhesion |
≥4B |
| Cover surface hardness |
≥6H |
| Total Thickness |
7.65mm |
| Display Thickness |
4.4mm |
| Display Active Area |
216.96*135.6mm |
| Display Outline Dimension |
213.22*150.6mm |
| Touch Panel Thickness |
2.75mm |
| Touch Panel Active Area |
217.96*136.6mm |
| Touch Panel View Area |
216.96*135.6mm |
| Cover Outline Dimension |
246.96*165.6mm |
| Screen Diagonal |
10.1/16:10 inch |
| Touch Panel P/N |
EG-10.1-A-1610V1 |
1.Special disinfectant-resistant hydrophobic anti-corrosion coating, resistant to repeated wiping with alcohol, chlorine-containing and peroxide disinfectants, preventing whitening and delamination
2.Upgrade panel to tempered glass with enhanced AG/AR coating, enduring over 50 daily high-frequency disinfections
3.Adopt full bonding packaging process to prevent disinfectant infiltration and circuit corrosion
4.Edge sealed with rubber gasket, prevent liquid residue from corroding base material
5.Raise anti-interference threshold to avoid sensitivity drop and false touch caused by coating damage
6.Algorithm optimized for disinfection scenarios, maintaining stable touch recognition precision
7.Dilute disinfectant properly, avoid wiping surface with undiluted solution
8.
Wipe residual liquid dry promptly to reduce prolonged surface adhesion
How to solve insensitive touch caused by liquid on surface？
1.Spray high-grade hydrophobic anti-condensation coating to block liquid film adhesion and eliminate water-caused false touch.
2.Enable water stain recognition filtering algorithm to shield invalid touch and restrain coordinate drift.
3.Avoid direct spraying on screen. Wipe residual liquid immediately after damp cleaning and keep surface free of water droplets.
4.Strengthen ESD and wet-state anti-interference performance, ensuring precise and stable operation of ventilators, monitors and other medical devices.
FAQ
1.Q: Can it withstand frequent disinfection cleaning?
A: Adopts corrosion-resistant glass and special coating, suitable for repeated wiping with various disinfectants.
2.Q: Will liquid on screen lead to poor touch response?
A: Hydrophobic coating and water filtering algorithm effectively avoid insensitive touch and false triggering.
3.Q: How to prevent disinfectant from damaging internal components?
A: Full lamination and edge sealing stop liquid infiltration and internal erosion.
4.Q: Does humid environment affect touch stability?
A: Improved anti-interference capability maintains accurate touch performance in damp conditions.
5.Q: What medical devices is this module applicable to?
A: Ideal for ventilators, patient monitors and other clinical medical equipment.
