Do you often encounter issues under extreme working conditions, such as severe screen glare under strong sunlight leading to poor visibility? Outdoor operating environments are usually harsh with excessively high temperatures. Long-term operation in high-temperature conditions tends to cause equipment overheating, resulting in touch lag, system crashes, or unresponsive touch functions.
1.Adopting 3mm high-strength tempered glass with an industrial-grade IK08 impact resistance rating. It effectively resists gravel impact, hard object collision and accidental bumps, strongly protecting the screen against damage. It delivers higher durability and safety for outdoor and complex working conditions.
2.Equipped with a 1000nits ultra-high brightness screen, it adopts dual coating technology of anti-glare AG and anti-reflection AR. It effectively reduces glare and improves light transmittance, realizing true sunlight readability and delivering clear and sharp images even under strong outdoor sunlight.
3.Lamination Process: Adopting full-fit OCA lamination technology, it reduces water vapor and fog accumulation inside the screen gap, and eliminates internal light refraction and capacitive signal disorder in humid environments.
4.
5.The front panel features an IP65 protection rating with a fully sealed dustproof structure. It resists high-pressure water spray and rain washing, perfectly adapting to complex industrial environments such as outdoor, humid and dusty conditions.
6.Industrial-grade projected capacitive touch (PCAP) supports stable operation with thick work gloves, labor gloves, wet hands and oily hands, delivering sensitive and reliable touch performance even in complex working conditions.
7.It features excellent shock and impact resistance, capable of withstanding heavy mechanical vibration of 5–10G (10–2000Hz). Fully compliant with ISO 16750-3 and MIL-STD-810G standards, it effectively withstands impacts from sudden braking, collisions and jolts in complex industrial scenarios. It ensures stable touch and display performance under harsh working conditions and eliminates potential functional failure risks.
8.The power supply adopts a wide-voltage DC design and supports 9–36V voltage input, which is directly compatible with 24V vehicle power supply scenarios. Meanwhile, it integrates three-level protection functions including overvoltage, undervoltage and reverse connection, effectively avoiding equipment damage caused by power anomalies and ensuring long-term stable operation of the device.
Specifications:
| Items |
Specifications |
| Cover Glass Thickness |
3MM |
| Pixels H×V |
1920 x 3(RGB) x 1080 |
| Contrast Ratio |
1000:1 |
| Luminance, white |
1000nits |
| Viewing Angle |
89 Typ. |
| Display Surface Treatment |
Anti-glare |
| Touch Report Rate |
≥100HZ |
| Impact resistance |
≥IK08 |
| Operation Conditions |
20%~90% RH |
Regular outdoor operation recommends a high-brightness configuration of
≥1000 cd/㎡, combined with AG anti-glare and AR anti-reflection coatings.
2.Why are ordinary capacitive touch screens unsuitable for excavators and loaders?Ordinary capacitive touch screens cannot adapt to heavy-duty working conditions. They do not support operation with thick work gloves, wet hands or oily surfaces. Besides, frequent equipment vibration on construction machinery easily causes ghost touches and touch drift. Meanwhile, they feature poor anti-electromagnetic interference performance, leading to random clicks and screen distortion under interference from motors and inverters.
3.What IP rating is required for the equipment，which is frequently washed with water and exposed to diesel oil and mud?The front panel of the complete machine shall reach
IP65 dustproof and waterproof rating, capable of withstanding high-pressure water gun flushing, rainwater and mud splashing.
4.Will the screen become loose or damaged due to long-term vibration and bumping of heavy machinery?Our custom industrial screens adopt a fully bonded reinforced structure, shock-resistant metal housing and enhanced soldering technology. They can withstand continuous vibration of 5–10G and high-intensity impact, perfectly adapting to the bumpy working conditions of heavy machinery.
5.How to choose between fully bonded and air-bonded screens for heavy industrial scenarios?Priority shall be given to the full lamination process. With no air interlayer inside the screen, it effectively eliminates glare, ghosting, internal fogging and dust accumulation.
